WHEN YOUR BIKE REMINDS YOUR OF YOUR FAVORITE CHILDHOOD CANDY, THIS TUTTI FRUTTI INSPIRED BIKE IS BUILT TO RACE, STRAIGHT OUT OF THE BOX.
-
DESCRIPTION
- Frame
- Series 3 custom butted and hydroformed 6066 alloy aluminium
- Frame Travel
- 211mm
- Fork Travel
- 200mm
- Wheel Size
- Mullet: 29" front / 27.5" rear
- Fork
- RockShox Boxxer Select RC
- Shock
- Marzocchi Bomber CR
- Drivetrain
- 1 x 7 SRAM GX DH
Explore the Benefits of Myst Pro
Built for the privateer racer, the Myst Pro is made to be hauled across the country and smashed down the nastiest downhill tracks.
Featuring the same Factory Team developed frame as the top model, the Pro is equally at home strapped to the back of an uplift trailer, or enjoying the once-a-year luxury of a chairlift in the Alps.
Our Tuned Ride link allows the suspension to be more active under braking, giving more traction when you need it most.
Please note - the Saracen Myst does not come supplied with pedals. Add some from our gear store!
-
DETAILS
- Variant: Large / Tutti Frutti
- SKU: RN25270LG
SKU: RN25270LG
Variant: Large / Tutti Frutti
Series 3 custom butted and hydroformed 6066 alloy
ALUMINIUM FRAME
211mm
FRAME TRAVEL
200mm
FORK TRAVEL
Mullet: 29'' front / 27.5'' rear
WHEEL SIZE
RockShox Boxxer Select RC
FORK
Marzocchi Bomber CR
SHOCK
1 x 7 SRAM GX DH
DRIVETRAIN
Full Specifications
-
FRAME: SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6066, OPTIMISED FACTORY RACING SIZING
Headtube
Custom headtube with adjustable front offset plus-minus 5mm
Bearings
37mm main pivot bearings / 28mm linkage bearings
Linkage
CNC custom mullet links
Suspension
Signature TRL suspension design
Cable Routing
Internal cable routing and integrated fork bump-stops
Axle
12 x 157mm rear axle
Rear Travel
211mm
-
FORK: ROCKSHOX BOXXER SELECT RC
Travel
200mm
Technology
DebonAir / low speed compression / rebound adjust
Axle
20x110 Maxle Stealth DH
-
REAR SHOCK: MARZOCCHI BOMBER CR
Adjustment
Low speed compression / Rebound
Spring Weight
250 x 75
-
CHAINSET: SRAM DESCENDANT
Model
DH
Chain Ring
34T
Crank Length
165mm
- BOTTOM BRACKET: SHIMANO BB52 83MM
-
SHIFTERS: SRAM GX
Model
DH
Speed
1x7 speed
-
REAR DERAILLEUR: SRAM GX
Model
DH
Speed
7 speed
- CHAIN DEVICE: MRP G4 CS
-
CASSETTE: SRAM PG720
Speed
7 speed
Ratio
11-25T
- CHAIN: KMC X11
-
BRAKES: SHIMANO BR-MT520
Brake Type
Hydraulic four piston
Rotor Size
203/203mm
- BRAKE LEVERS: SHIMANO BL-MT501
-
HUBS: FORMULA/KT
Front
DHL-93 sealed bearing 32H
Rear
KT M5HR sealed bearing 32H
Brake Fitting
6-bolt
Front Axle Type
20mm thru axle
Rear Axle Type
12 x 157mm Saracen Taper-Lock
Hole
32H
-
RIMS: RACEFACE ARC
Hole
32H
Size
29'' front / 27.5'' rear
Tubeless Ready
Yes
- SPOKES: DOUBLE-BUTTED STAINLESS STEEL
-
TYRES: HIGH ROLLER 3
Model
3CMaxxGrip DH TR
Size
29 x 2.5 front / 27.5 x 2.5 rear
-
HANDLEBARS: RACEFACE CHESTER ALLOY
Width
780mm
Rise
20mm
Bend
5 degree up bend / 8 degree sweep
Bar Bore
35mm
-
STEM: RACEFACE CHESTER
Length
50mm
Clamp
35mm
Type
Direct mount
- HEADSET: CUSTOM SARACEN HEADSET / 0MM OFFSET INSTALLED
-
SEAT POST: RACEFACE CHESTER
Size
30.9mm
Length
325mm
- SADDLE: SARACEN CUSTOM DH CRMO MTB
- GRIPS: ODI ELITE MOTION
- EXTRAS: CUSTOM CHAINSTAY PROTECTOR
- COLOUR: BLUE
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
Please be advised that this sizing chart is designed as a rough guide to help you select the size you require. Although height is one key factor on choosing the correct size bike, there are others which are discussed in our in-depth size guide feature.
Geometry
- 1251MM
- Wheelbase
SEAT TUBE |
410mm |
|---|---|
TOP TUBE |
607mm |
FRAME REACH |
455mm |
FRAME STACK |
624mm |
HEAD TUBE |
100mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1271mm |
SEAT TUBE |
410mm |
TOP TUBE |
641mm |
FRAME REACH |
485mm |
FRAME STACK |
624mm |
HEAD TUBE |
100mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1306mm |
SEAT TUBE |
410mm |
TOP TUBE |
661mm |
FRAME REACH |
505mm |
FRAME STACK |
633mm |
HEAD TUBE |
110mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1326mm |
