THIS STEALTH BOMMER OF A BIKE WILL SEE YOU FLY PAST UNDETECTED AND LAPPING FASTER THAN ANY OF YOUR MATES!
-
DESCRIPTION
- Frame
- Series 3 custom butted and hydroformed 6066 alloy aluminium
- Frame Travel
- 211mm
- Fork Travel
- 200mm
- Wheel Size
- Mullet: 29" front / 27.5" rear
- Fork
- RockShox Boxxer Select RC
- Shock
- Marzocchi Bomber CR
- Drivetrain
- 1 x 7 SRAM GX DH
Explore the Features and Benefits of Myst Pro
Built for the privateer racer, the Myst Pro is made to be hauled across the country and smashed down the nastiest downhill tracks.
Featuring the same Factory Team developed frame as the top model, the Pro is equally at home strapped to the back of an uplift trailer, or enjoying the once-a-year luxury of a chairlift in the Alps.
Our Tuned Ride link allows the suspension to be more active under braking, giving more traction when you need it most.
Please note - the Saracen Myst does not come supplied with pedals. Add some from our gear store!
-
DETAILS
- Variant: Large / Black
- SKU: RN25260LG
-
FAQ
-
Q: What suspension setup is best for downhill riding?
A: The best downhill suspension setup depends on rider weight, riding style and terrain. As a starting point, aim for 25-30% sag, then fine-tune your rebound and compression settings to balance grip, support and responsiveness.Q: How much suspension travel dose the Myst have?
A: The Myst feature around 200mm of front and 211mm rear suspension travel. This amount of travel is designed to absorb large impacts, rough terrain, jumps and steep descents while maintaining control at high speeds.Q: What makes the Saracen Myst different from other downhill bikes?
A: The Saracen Myst is a race-proven downhill bike developed alongside the Madison Saracen Factory Race Team, built to deliver maximum speed, control and confidence on technical descents.Q: What wheel size does the Saracen Myst use?
A: The Myst uses a dedicated mullet setup, pairing a 29-inch front wheel with a 27.5-inch rear wheel to balance stability, speed and agility.Q: What forks do Saracen Myst bikes come with?
A: Saracen Myst bikes are equipped with premium downhill-specific forks, with the Myst Team LTD featuring a Fox 40 Float Factory fork and the Myst Pro LTD fitted with a RockShox Boxxer Select RC. Both models offer 200mm of travel for maximum control on steep, technical terrain and bike park laps.Q: What type of riding is the Myst best for?
A: The Myst is designed specifically for downhill riding, including bike parks, race tracks, and very steep, technical descents. It performs best in environments where speed, stability, and control on rough terrain are the priority. It is not intended for general trail riding or long-distance climbing.Q: What level of rider is the Myst aimed at?
A: The Myst is aimed at intermediate to advanced riders who already have experience riding technical terrain at speed. It is commonly used by downhill riders and racers who require a purpose-built gravity bike. It is not suitable as a first mountain bike or for casual trail riding.
-
Series 3 custom butted and hydroformed 6066 alloy
ALUMINIUM FRAME
211mm
FRAME TRAVEL
200mm
FORK TRAVEL
Mullet: 29'' front / 27.5'' rear
WHEEL SIZE
RockShox Boxxer Select RC
FORK
Marzocchi Bomber CR
SHOCK
1 x 7 SRAM GX DH
DRIVETRAIN
Full Specifications
-
FRAME: SERIES 3 CUSTOM BUTTED AND HYDROFORMED 6066, OPTIMISED FACTORY RACING SIZING
Headtube
Custom headtube with adjustable front offset plus-minus 5mm
Bearings
37mm main pivot bearings / 28mm linkage bearings
Linkage
CNC custom mullet links
Suspension
Signature TRL suspension design
Cable Routing
Internal cable routing and integrated fork bump-stops
Axle
12 x 157mm rear axle
Rear Travel
211mm
-
FORK: ROCKSHOX BOXXER SELECT RC
Travel
200mm
Technology
DebonAir / low speed compression / rebound adjust
Axle
20x110 Maxle Stealth DH
-
REAR SHOCK: MARZOCCHI BOMBER CR
Adjustment
Low speed compression / Rebound
Spring Weight
250 x 75
-
CHAINSET: SRAM DESCENDANT
Model
DH
Chain Ring
34T
Crank Length
165mm
- BOTTOM BRACKET: SHIMANO BB52 83MM
-
SHIFTERS: SRAM GX
Model
DH
Speed
1x7 speed
-
REAR DERAILLEUR: SRAM GX
Model
DH
Speed
7 speed
- CHAIN DEVICE: MRP G4 CS
-
CASSETTE: SRAM PG720
Speed
7 speed
Ratio
11-25T
- CHAIN: KMC X11
-
BRAKES: SHIMANO BR-MT520
Brake Type
Hydraulic four piston
Rotor Size
203/203mm
- BRAKE LEVERS: SHIMANO BL-MT501
-
HUBS: FORMULA/KT
Front
DHL-93 sealed bearing 32H
Rear
KT M5HR sealed bearing 32H
Brake Fitting
6-bolt
Front Axle Type
20mm thru axle
Rear Axle Type
12 x 157mm Saracen Taper-Lock
Hole
32H
-
RIMS: RACEFACE ARC
Hole
32H
Size
29'' front / 27.5'' rear
Tubeless Ready
Yes
- SPOKES: DOUBLE-BUTTED STAINLESS STEEL
-
TYRES: HIGH ROLLER 3
Model
3CMaxxGrip DH TR
Size
29 x 2.5 front / 27.5 x 2.5 rear
-
HANDLEBARS: RACEFACE CHESTER ALLOY
Width
780mm
Rise
20mm
Bend
5 degree up bend / 8 degree sweep
Bar Bore
35mm
-
STEM: RACEFACE CHESTER
Length
50mm
Clamp
35mm
Type
Direct mount
- HEADSET: CUSTOM SARACEN HEADSET / 0MM OFFSET INSTALLED
-
SEAT POST: RACEFACE CHESTER
Size
30.9mm
Length
325mm
- SADDLE: SARACEN CUSTOM DH CRMO MTB
- GRIPS: ODI ELITE MOTION
- EXTRAS: CUSTOM CHAINSTAY PROTECTOR
- COLOUR: BLUE
166
168
170
172
174
176
178
180
182
184
186
188
190
192
194
196
Please be advised that this sizing chart is designed as a rough guide to help you select the size you require. Although height is one key factor on choosing the correct size bike, there are others which are discussed in our in-depth size guide feature.
Geometry
- 1251MM
- Wheelbase
SEAT TUBE |
410mm |
|---|---|
TOP TUBE |
607mm |
FRAME REACH |
455mm |
FRAME STACK |
624mm |
HEAD TUBE |
100mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1271mm |
SEAT TUBE |
410mm |
TOP TUBE |
641mm |
FRAME REACH |
485mm |
FRAME STACK |
624mm |
HEAD TUBE |
100mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1306mm |
SEAT TUBE |
410mm |
TOP TUBE |
661mm |
FRAME REACH |
505mm |
FRAME STACK |
633mm |
HEAD TUBE |
110mm |
HEAD ANGLE |
63.0° |
SEAT ANGLE |
76.5° |
CHAINSTAY |
450mm |
BB DROP |
9mm |
WHEELBASE |
1326mm |
